Description
Engine
Type: Air – Cooled, 4 – Stroke Single Cylinder OHC
Displacement: 110.9 cc
Max Power: 6 kW (8 BHP) @ 7500 rpm
Max Torque: 8.7 Nm @ 5500 rpm
Starting System: Self-Start / Kick-Start
Transmission & Chassis
Clutch: Automatic Clutch
Gear box: Variomatic Drive (2.51 – 0.85)
Suspension
Front: Telescopic, Hydraulic Shock Absorbers
Rear: Unit Swing with Spring Loaded Hydraulic Damper
Wheels & Tyres
Tyre Size Front: 90/90 – 12 – 54 J
Tyre Size Rear: 90/100 – 10 – 53 J
Dimensions
L X W X H: 1841 mm x 695 mm x 1190 mm
Wheelbase: 1261 mm
Ground Clearance: 155 mm
Kerb Weight: 110 Kg
Max Payload: 130 Kg
Electricals
Battery: 12V-4Ah (MF Battery)
Head Lamp: 12V-35W/35W – Halogen Bulb (Multi – Reflector Type)
Tail/Stop Lamp: 12V-0.4/1.6W – (LED Type)
Turn Signal Lamp: 12V-10 W x 4 nos – (MFR – Clear Lens – Amber Bulb Type)
