Product Descriptions
ENGINE
Engine Type: 4-Stroke, SOHC, eSP
Bore × Stroke: 47.0 × 63.1 mm
Displacement: 109.5 cc
Compression Ratio: 10.0 : 1
Maximum Power: 6.6 kW (9.0 PS) @ 7,500 rpm
Maximum Torque: 9.2 Nm (0.94 kgf·m) @ 6,000 rpm
Clutch Type: Automatic, Centrifugal, Dry Type
Starter System: Electric & Kick Starter (CBS Type);
Electric Only (Deluxe & Deluxe Smart Key Type)
Spark Plug: NGK MR9C-9N
Fuel System: PGM-FI (Fuel Injection)
Transmission Type: Automatic, V-Matic
Ignition System: Full Transistorized
FRAME & SUSPENSION
Frame Type: Underbone – eSAF (Enhanced Smart Architecture Frame)
Front Suspension: Telescopic
Rear Suspension: Swing Arm with Single Shock Absorber
TYRES
Front Tyre: 80/90 – 14 M/C 40P Tubeless
Rear Tyre: 90/90 – 14 M/C 46P Tubeless
BRAKES
Front Brake: Hydraulic Disc with Single Piston
Rear Brake: Drum
Braking System: Combi Brake System
DIMENSIONS & WEIGHT
Overall Length × Width × Height: 1,876 × 669 × 1,080 mm
Wheelbase: 1,255 mm
Ground Clearance: 148 mm
Kerb Weight: 88 kg (CBS Type) / 87 kg (Deluxe & Deluxe Smart Key Type)
Seat Height: 742 mm
CAPACITY
Fuel Tank Capacity: 4.2 L
Engine Oil Capacity: 0.65 L (For Periodic Replacement)
ELECTRICAL
Battery: MF 12V–3Ah (CBS Type)
Ignition System: MF 12V–5Ah (Deluxe & Deluxe Smart Key Type)
