Product Descriptions
BODY DIMENSIONS
Length: 1,781 mm
Width: 710 mm
Height: 1,133 mm
Wheelbase: 1,238 mm
Ground Clearance: 158 mm
Kerb Weight: 103 kg
Fuel Tank Capacity: 5.3 L
ENGINE
Type: Fan Cooled, 4-Stroke, SI, BS-IV Engine
Displacement: 109.19 cc
Max Net Power: 8.11 PS (8 BHP) @ 7,000 rpm
Max Net Torque: 8.91 Nm @ 5,500 rpm
Bore x Stroke: 50 x 55.6 mm
Compression Ratio: 9.5:1
Air Filter Type: Viscous Paper Filter
Starting Method: Kick & Self
TRANSMISSION
Number of Gears: N/A (Automatic)
Gear Pattern: N/A
Max Speed: 83 km/h
TYRES & BRAKES
Front Tyre: 90/100-10 53J Tubeless, 10 inch
Rear Tyre: 90/100-10 53J Tubeless, 10 inch
Front Brake: Drum, 130 mm
Rear Brake: Drum, 130 mm (CBS)
FRAME & SUSPENSION
Frame Type: Underbone
Front Suspension: Tube Type
Rear Suspension: Tube Type
ELECTRICALS
Battery: 12V, 3Ah (Maintenance Free)
Headlamp: 12V, 35/35W
