Product Descriptions
ENGINE
Engine Type: 4-Stroke, 4-Valve, eSP+
Cooling System: Liquid-Cooled
Fuel Supply System: PGM-FI (Programmed Fuel Injection)
Displacement: 156.9 cc
Bore x Stroke: 60 x 55.5 mm
Compression Ratio: 12:1
Maximum Power: 11.8 kW (16 PS) / 8,500 rpm
Maximum Torque: 14.7 Nm (1.5 kgf·m) / 6,500 rpm
Transmission Type: Automatic, V-Matic
Starter Type: Electric
Clutch Type: Automatic, Centrifugal, Dry Type
Lubricant Capacity: 0.8 L (Periodic Change)
FRAME & SUSPENSION
Frame Type: Double Cradle
Front Suspension: Telescopic
Rear Suspension:
CBS & ABS: Dual Rear Suspension
RoadSync: Dual Rear Suspension with Reservoir
TYRES
Front Tyre: 110/70 – 14 M/C Tubeless
Rear Tyre: 130/70 – 13 M/C Tubeless
BRAKES
Front Brake:
CBS: Triple Pots Hydraulic, Combi Brake System
ABS & RoadSync: Anti-Lock Braking System
Rear Brake: Hydraulic Disc
DIMENSIONS & WEIGHT
Length x Width x Height: 1,936 x 742 x 1,123 mm
Wheelbase: 1,313 mm
Ground Clearance: 135 mm
Seat Height: 764 mm
Curb Weight: 132 kg (CBS), 132 kg (ABS), 133 kg (RoadSync)
Fuel Tank Capacity: 8.1 L
ELECTRICAL
Ignition System: Fully Transistorized
Battery: 12 V – 5 Ah, MF Type
Spark Plug Type: NGK LMAR8L-9
Power Charger: 5V, 3A
