Product Descriptions
ENGINE
Engine Type: 4-Stroke, SOHC, eSP
Cooling Type: Air-Cooled
Fuel Supply System: PGM-FI (Programmed Fuel Injection)
Displacement: 109.5 cc
Bore x Stroke: 47 x 63.1 mm
Compression Ratio: 10.0:1
Maximum Power: 6.6 kW (9.0 PS) / 7,500 rpm
Maximum Torque: 9.2 Nm (0.94 kgf·m) / 6,000 rpm
Transmission Type: Automatic, V-Matic
Starter Type: Electric & Kick Starter (STD) / Electric (Smart Key)
Clutch Type: Automatic, Centrifugal, Dry Type
Lubricant Capacity: 0.65 L (Periodic Change)
Lubricant Type: Wet
FRAME & SUSPENSION
Frame Type: Underbone – eSAF (Enhanced Smart Architecture Frame)
Front Suspension: Telescopic
Rear Suspension: Swing Arm with Single Shock Absorber
TYRES
Front Tyre: 100/90 – 12 59J (Tubeless)
Rear Tyre: 110/90 – 12 64J (Tubeless)
BRAKES
Front Brake: Hydraulic Disc with Single Piston
Rear Brake: Drum
Braking System: Combi Brake System (CBS)
DIMENSIONS & WEIGHT
Length x Width x Height: 1,869 x 693 x 1,075 mm
Wheelbase: 1,251 mm
Ground Clearance: 145 mm
Seat Height: 746 mm
Curb Weight: 94 kg (STD) / 93 kg (Smart Key)
Fuel Tank Capacity: 4.2 L
ELECTRICAL
Ignition System: Fully Transistorized
Battery Type: MF 12V-5Ah
Spark Plug Type: NGK MR9C-9N / DENSO U27EPR-N9
