Honda Vario

Description

ENGINE

Engine Type: 4-Stroke, 4-Valve, eSP+

Cooling System: Liquid-Cooled

Fuel Supply System: PGM-FI (Programmed Fuel Injection)

Displacement: 156.9 cc

Bore x Stroke: 60 x 55.5 mm

Compression Ratio: 12:1

Maximum Power: 11.3 kW (15.4 PS) / 8,500 rpm

Maximum Torque: 13.8 Nm (1.4 kgf·m) / 7,000 rpm

Transmission Type: Automatic, V-Matic

Starter Type: Electric

Clutch Type: Automatic, Centrifugal, Dry Type

Lubricant Type: Wet

Lubricant Capacity: 0.8 L (Periodic Change)

FRAME & SUSPENSION

Frame Type: Underbone – eSAF (Enhanced Smart Architecture Frame)

Front Suspension: Telescopic

Rear Suspension: Swing Arm with Single Shock Absorber

TYRES

Front Tyre: 100/80 – 14 M/C Tubeless

Rear Tyre: 120/70 – 14 M/C Tubeless

BRAKES

Front Brake:

Vario 160 ABS: 220 mm Hydraulic Disc

Vario 160 CBS: 190 mm Hydraulic Disc

Rear Brake:

Vario 160 ABS: 220 mm Hydraulic Disc

Vario 160 CBS: Drum

Braking System: Combi Brake System (CBS) & Anti-Lock Braking System (ABS)

DIMENSIONS & WEIGHT

Length x Width x Height: 1,929 x 679 x 1,088 mm

Wheelbase: 1,277 mm

Ground Clearance: 140 mm

Seat Height: 778 mm

Curb Weight: 115 kg (CBS) & 117 kg (ABS)

Fuel Tank Capacity: 5.5 L

ELECTRICAL

Ignition System: Fully Transistorized

Battery Type: 12V-5Ah, MF

Spark Plug Type: NGK LMAR8L-9
