Product Descriptions
Engine
Engine Type: Air-cooled, 4-stroke, SOHC, 2-valve
Hybrid: Equipped
Displacement: 125 cc
Bore & Stroke: 52.4×57.9mm
Maximum Torque (With Assist Function Working): 10.3 N.m(1.1kgf.m)/5000 r/min
Compression Ratio: 10.2:1
Maximum horse power: 6.0kW(8.2PS)/6500r/min
Stop & Start System (SSS): Equipped
Fuel System: Fuel injection
Starting system type: Electric starter
Transmission type: V-Belt Automatic
Smart Motor Generator(SMG) System: Equipped
Dimensions
Overall Length x Width x Height: 1,880 x 750 x 1,190 (Spec. in mm)
Seat height: 785 mm
Wheelbase: 1,280 mm
Minimum ground clearance: 145 mm
Kerb Weight (with oil and full fuel tank): 99 kg
Fuel tank capacity: 5.2 L
Underseat Storage: 21 L
Chassis
Suspension type (Front/Rear): Telescopic fork/Unit swing
Tyre size (Front): 90/90-12 Tubeless
Tyre size (Rear): 110/90-10 Tubeless
UBS: Equipped
Brake type (Front): Disc 190mm
Brake type (Rear): Drum
Electrical
Battery: Maintenance free – 12V,5.0 Ah
Ignition system: TCI (Transistor Controlled Ignition)
Answer Back: Equipped
Brake/tail light: 12V,21/5W x 1
DRL/Position light: LED
Side stand engine cut-off switch: Equipped
Meter Console: Digital
Y-Connect: Equipped
